► The first adjustable speed, low 150 (r.p.m) ~ 1000 (r.p.m) free to set the speed, LED speed indication, constant torque, easy to tighten the range of different precision.
► Both forward / reverse switch are button switch mode, convenient one-handed operation, without switching the positive and negative switch, improve work efficiency.
► Adopt high-performance low voltage brushless motor without dust, low noise, durability, no maintenance, and meet the requirements of environmental protection.
Small size, light weight, streamlined shell design, suitable for a large number of grips, ergonomic design.
► Full range of shell models using the United States DuPont anti-static PC raw materials processing.
|
Model(Item NO.)
|
TF-8216L
|
TF-8325L
|
TF-8330L
|
TF-8338L
|
|
Input Voltage Input
|
32Vdc
|
|
Torque
(Torque Range)
|
Kgf-cm
|
2.0~16
|
3.0~25
|
10.0~40
|
15.0~50
|
|
Lbf-in
|
1.8~15.2
|
2.7~25.
|
8.7~34.7
|
2.6~43.5
|
|
N-m
|
0.2~1.53
|
0.27~2.5
|
--
|
0.29~1.94
|
|
Air speedr.p.m.
|
300/800 /1000
|
|
Screw
(m/m)
|
Machine Screw diameter Ø
(Machine)
|
2.6~4.0(mm)
0.10~0.16(in)
|
3.0~5.0(mm)
0.12~0.20(in)
|
4.0~5.5(mm)
0.12~0.22(in)
|
2.6~4.0(mm)
0.10~0.24(in)
|
|
Tapping Ø Drive
(Tapping)
|
2.3~3.5(mm)
0.09~0.14(in)
|
2.6~4.0(mm)
0.10~0.16(in)
|
3.0~4.5(mm)
0.10~0.18(in)
|
2.3~5.0(mm)
0.09~0.20(in
|
|
